第 11 章实战章的学员管理部分——把六个接口(新增、条件分页、详情、修改、批量删除、违纪处理)从接口文档落成三层代码,重点讲动态 SQL 的条件查询与按需更新、关联查出班级名称的列表 SQL,以及带两个路径参数、在一条 SQL 里把违纪次数加一与扣分累加的违纪处理,最后附本机实测的响应与库里的数据变化
.webp)
77 篇给首页那两张图表喂上了数据,员工这一摊算是收尾了。可 Tlias 的侧边栏里还挂着两块没有后端的功能——班级学员管理和数据统计:这两块的表(clazz、student)在 64 篇就建好、数据也灌好了,但接口一个都还没写。**第 11 章(项目实战)**要做的事,就是把它们从接口文档一路做到能和前端联调。
这一章的 PPT 只有 7 页(封面、需求、最终效果、“暂停视频完成实战”、“实战说明”),没有一句技术讲解——它是”实战章”:需求给你、接口文档给你,前面 10 章学的三层架构、MyBatis、动态 SQL、分页、异常处理,自己挑着用。所以这三篇笔记不写”PPT 上讲了……”,写法是需求 + 接口约定 + 实现思路 + 课程参考实现的关键代码 + 本机实测,给你对照自己写的那份代码:
| 模块(PPT 第 2、3 页的需求清单) | 落点 |
|---|---|
| 班级管理:班级列表查询、删除班级、添加班级、修改班级 | 78 篇 |
| 学员管理:学员列表查询、删除学员、添加学员、修改学员、违纪处理 | 本篇(79) |
| 数据统计:班级人数统计、学员学历统计 | 80 篇 |
PPT 第 3 页在清单底下补了一句,这是整章的规矩:
注意:所有的功能全部严格,根据接口文档进行开发,并进行前后端联调。
“严格”两个字落在三处:请求路径、请求方式、参数格式(查询参数 / 路径参数 / JSON 请求体)——都要和 资料\02. 接口文档\ 一字不差。前端不归你写,但后端吐出来的 JSON 结构必须正好是前端要的样子,否则联调时就是来回改。
第 5、6 页是实战的安排:暂停视频,把全部实战需求做完再往下学;以小组为单位完成,卡住了先自己想、再组内讨论,最后每组选一个人上来演示,演示时要讲清楚自己的实现思路,以及过程中遇到的典型 Bug、产生的原因和解决方案。一个人从零做完也没问题,下面照旧把每个功能拆开讲。
PPT 第 2 页放了班级管理、学员管理、数据统计三张需求图,学员管理这张长这样(图中是原型里的假数据):

需求图对应的五个功能,在 资料\02. 接口文档\离线\api接口文档.md 第 4 节”学员管理”里是六个接口(新增、修改各一个,查询分成”列表”和”详情”两个):
| 功能 | 请求路径 | 请求方式 | 参数格式 | 参数说明 |
|---|---|---|---|---|
| 学员列表查询 | /students | GET | queryString | name(姓名,模糊)、degree(学历)、clazzId(班级)都可选;page 默认 1、pageSize 默认 10 |
| 添加学员 | /students | POST | application/json | 请求体里是学员 JSON:name/no/gender/phone/degree/clazzId 必须,idCard/isCollege/address/graduationDate 非必须 |
| 根据 ID 查询 | /students/{id} | GET | 路径参数 | id(学员 ID) |
| 修改学员 | /students | PUT | application/json | 请求体里是学员 JSON,带 id;violationCount/violationScore 也在提交的字段里 |
| 删除学员 | /students/{ids} | DELETE | 路径参数 | ids(学员的 ID 数组),样例 /students/1,2,3 |
| 违纪处理 | /students/violation/{id}/{score} | PUT | 路径参数 | id(学员 ID)、score(扣除分数) |
接口文档里有两处特别容易踩,先圈出来:
DELETE /students/1,2,3。而 74 篇的员工删除是 DELETE /emps?ids=1,2,3(查询参数)——名字像、地址格式不一样,照抄员工那套会直接 404。以接口文档为准,这也是”严格按接口文档开发”最真实的例子。/students/violation/{id}/{score},既不是查询参数、也不是请求体。PPT 第 4 页放的是三个页面做完之后的截图(班级管理、学员管理、数据统计各一张),学员管理这张是:

student 与实体类#学员管理只在 student 一张表上做增删改查。这张表的建表脚本在 资料\03. 表结构\表结构.sql 里,建在 tlias 库上(课程示例连的是 root / 1234,password 换成你自己 MySQL 的密码):
| 列 | 类型 / 约束 | 说明 |
|---|---|---|
id | int unsigned,主键、自增 | 学员 ID |
name | varchar(10),非空 | 姓名 |
no | char(10),非空,唯一 | 学号 |
gender | tinyint unsigned,非空 | 性别,1 男 2 女 |
phone | varchar(11),非空,唯一 | 手机号 |
id_card | char(18),非空,唯一 | 身份证号 |
is_college | tinyint unsigned,非空 | 是否来自院校,1 是 0 否 |
address | varchar(100) | 联系地址 |
degree | tinyint unsigned | 最高学历,1 初中、2 高中、3 大专、4 本科、5 硕士、6 博士 |
graduation_date | date | 毕业时间 |
clazz_id | int unsigned,非空 | 班级 ID,关联班级表 clazz.id |
violation_count | tinyint unsigned,非空、默认 0 | 违纪次数 |
violation_score | tinyint unsigned,非空、默认 0 | 违纪扣分 |
create_time / update_time | datetime | 创建时间 / 修改时间 |
表里专门为违纪功能准备的两条字段——violation_count(违纪次数)和 violation_score(违纪扣分)——是违纪处理功能的数据基础:每次违纪处理,次数加一、扣分往上累加。它们都有默认值 0,所以新增学员时不用管,insert 语句里也不写这两列。
另外请注意三个唯一约束:no(学号)、phone(手机号)、id_card(身份证号)。新增或修改学员时只要和库里已有的学员撞上,SQL 就会被数据库拦下(Duplicate entry '...' for key 'student.no');在我们的工程里,这个错误会被 76 篇的全局异常处理器接住,前端拿到的是 {"code":0,"msg":"'xxx' 已存在","data":null} 这样的友好提示,而不是 500。自己增删改测试数据时,这三个字段最容易撞。
实体类 Student 是课程直接给的(资料\04. 基础代码\Student.java),字段与表列一一对应:
1@Data2@NoArgsConstructor3@AllArgsConstructor4public class Student {5 private Integer id; //ID6 private String name; //姓名7 private String no; //学号8 private Integer gender; //性别 , 1: 男 , 2 : 女9 private String phone; //手机号10 private String idCard; //身份证号11 private Integer isCollege; //是否来自于院校, 1: 是, 0: 否12 private String address; //联系地址13 private Integer degree; //最高学历, 1: 初中, 2: 高中 , 3: 大专 , 4: 本科 , 5: 硕士 , 6: 博士14 private LocalDate graduationDate; //毕业时间15 private Integer clazzId; //班级ID16 private Short violationCount; //违纪次数17 private Short violationScore; //违纪扣分18 private LocalDateTime createTime; //创建时间19 private LocalDateTime updateTime; //修改时间20
21 private String clazzName;//班级名称22}两个细节:
id_card)、属性名是小驼峰(idCard),靠 yml 里的驼峰开关 map-underscore-to-camel-case: true 对上(58 篇)。clazzName 不是表里的列——它是列表查询时关联班级表查出来的班级名称,专门给前端表格里”班级”那一列显示用。课程数据里学员表一共 18 条(本机实测),按班级分布是这样的(做筛选类题目对答案时用得上):
clazz_id | 人数 | 对应班级 |
|---|---|---|
| 1 | 6 | JavaEE就业163期 |
| 2 | 7 | ⚠️ 班级表里没有 id=2 这个班级(课程数据本身如此) |
| 4 | 3 | 前端就业90期 |
| 8 | 2 | JavaEE就业167期 |
学历分布是初中 1、高中 4、大专 3、本科 8、硕士 2,合计 18。clazz_id=2 那 7 个人在做”班级人数统计”时不会出现在结果里(80 篇会讲原因),但学员列表按 clazzId=2 筛选是能筛出来的——因为列表查的是 student 表。
学员管理这一套和前面员工、部门那几套是同一个骨架:Controller 只管接参和响应、Service 管业务和补时间字段、Mapper 管 SQL。先把六个接口的分工摊开看一眼,后面再逐个说:
| 功能 | Controller | Service | Mapper |
|---|---|---|---|
| 新增 | @PostMapping save(@RequestBody Student) | 补 createTime/updateTime 再调 insert | 注解 @Insert 写 insert |
| 列表查询 | @GetMapping page(name, degree, clazzId, page, pageSize) | PageHelper.startPage + 强转 Page 取 total | XML:关联班级 + 动态条件 + 排序 |
| 详情 | @GetMapping("/{id}") | 直接返回 Mapper 结果 | 注解 @Select 单表查 |
| 修改 | @PutMapping update(@RequestBody Student) | 补 updateTime 再调 update | XML:<set> + <if> 按需更新 |
| 删除 | @DeleteMapping("/{ids}") | 透传 | XML:delete ... in + <foreach> |
| 违纪处理 | @PutMapping("/violation/{id}/{score}") | 透传 | 注解 @Update:次数 +1、分数累加 |
课程工程里的 StudentController 一次把这六个接口都写出来了,下面是它的”目录”(每个方法的实现后面分节讲):
1@Slf4j2@RestController3@RequestMapping("/students") // 类上统一 /students,方法上只写剩下的部分4public class StudentController {5
6 @Autowired7 private StudentService studentService;8
9 @PostMapping // 新增:POST /students(请求体是 JSON)10 public Result save(@RequestBody Student student){ ... }11
12 @GetMapping // 列表:GET /students?name=°ree=&clazzId=&page=&pageSize=13 public Result page(String name, Integer degree, Integer clazzId,14 @RequestParam(defaultValue = "1") Integer page,15 @RequestParam(defaultValue = "10") Integer pageSize){ ... }16
17 @GetMapping("/{id}") // 详情:GET /students/818 public Result getInfo(@PathVariable Integer id){ ... }19
20 @PutMapping // 修改:PUT /students(请求体是 JSON,带 id)21 public Result update(@RequestBody Student student){ ... }22
23 @DeleteMapping("/{ids}") // 删除:DELETE /students/1,2,324 public Result delete(@PathVariable List<Integer> ids){ ... }25
26 @PutMapping("/violation/{id}/{score}") // 违纪处理:PUT /students/violation/1/527 public Result violationHandle(@PathVariable Integer id, @PathVariable Integer score){ ... }28}(省略号处的方法体下面逐条展开。)每个方法都只有”接参 → 调 Service → Result.success(...)”三句话,业务逻辑一行都不写——这是 58 篇以来一直没变的分工。
POST /students#需求与接口约定:页面上点「+ 新增学员」弹出表单,填完提交;前端把学员信息以 JSON 放进请求体 POST 到 /students。请求体样例(接口文档 4.3):
1{2 "name": "阿大",3 "no": "2024010801",4 "gender": 1,5 "phone": "15909091235",6 "idCard": "159090912351590909",7 "isCollege": 1,8 "address": "昌平回龙观",9 "degree": 4,10 "graduationDate": "2024-01-01",11 "clazzId": 912}JSON 里的字段名(clazzId、graduationDate、isCollege、idCard)要和 Student 的属性名对应,SpringMVC 才能把请求体反序列化成对象;"2024-01-01" 这样的字符串会自动转成 LocalDate。
实现:控制层用 @RequestBody 接整个对象,业务层补上两个时间字段,数据访问层把记录写进表。
1// Controller2@PostMapping3public Result save(@RequestBody Student student){4 studentService.save(student);5 return Result.success();6}1// ServiceImpl2@Override3public void save(Student student) {4 // 创建时间、修改时间由后端统一填(前端不传)5 student.setCreateTime(LocalDateTime.now());6 student.setUpdateTime(LocalDateTime.now());7 studentMapper.insert(student);8}1// StudentMapper(字段多、一行写得太长,课程用注解把 insert 写在这里)2@Insert("insert into student(name, no, gender, phone,id_card, is_college, address, degree, graduation_date,clazz_id, create_time, update_time) VALUES " +3 "(#{name},#{no},#{gender},#{phone},#{idCard},#{isCollege},#{address},#{degree},#{graduationDate},#{clazzId},#{createTime},#{updateTime})")4void insert(Student student);三个要点:
insert 的列里没有 violation_count、violation_score——让数据库用默认值 0(新学员当然没违过纪);create_time、update_time 也不在前端提交的字段里,由 Service 用 LocalDateTime.now() 补上(69 篇新增员工是同一套做法);no / phone / id_card)重复时会走全局异常处理器返回 {"code":0,"msg":"'xxx' 已存在","data":null},所以调试时换个学号/手机号再试。GET /students#需求与接口约定:页面顶部三个条件——姓名(模糊查询)、最高学历(精确)、所属班级(精确),三个都可以不填;结果按最后操作时间倒序、分页展示(接口文档 4.1 的样例是 /students?name=张三°ree=1&clazzId=2&page=1&pageSize=5)。列表里”班级”那一列显示的是班级名称,而 student 表里只有 clazz_id。
三层实现:
1// Controller2@GetMapping3public Result page(String name,4 Integer degree,5 Integer clazzId,6 @RequestParam(defaultValue = "1") Integer page,7 @RequestParam(defaultValue = "10") Integer pageSize){8 PageResult pageResult = studentService.page(name, degree, clazzId, page, pageSize);9 return Result.success(pageResult);10}1// ServiceImpl:分页交给 PageHelper([67 篇](/posts/编程学习/javaweb学习笔记/67-分页查询的两种实现方式/))2@Override3public PageResult page(String name, Integer degree, Integer clazzId, Integer page, Integer pageSize) {4 PageHelper.startPage(page, pageSize); // 1. 设置分页参数5
6 List<Student> studentList = studentMapper.list(name, degree, clazzId); // 2. 紧跟着的这条查询会被分页7 Page<Student> p = (Page<Student>) studentList; // 3. 强转成 Page 才能拿 total8
9 return new PageResult(p.getTotal(), p.getResult());10}1<!-- StudentMapper.xml:关联班级 + 动态条件 + 排序 -->2<select id="list" resultType="com.itheima.pojo.Student">3 select s.*, c.name clazzName from student s left join clazz c on s.clazz_id = c.id4 <where>5 <if test="name != null and name != ''">6 s.name like concat('%',#{name},'%')7 </if>8 <if test="degree != null">9 and s.degree = #{degree}10 </if>11 <if test="clazzId != null">12 and s.clazz_id = #{clazzId}13 </if>14 </where>15 order by s.update_time desc16</select>1// StudentMapper 接口里对应的方法声明(实现在 XML 里)2List<Student> list(String name, Integer degree, Integer clazzId);几个值得停一下的地方:
left join clazz:前端表格里的”班级”列要显示”西安黑马JavaEE就业300期”这样的名字,而 student 表里只有 clazz_id。所以查询时把班级表连进来,c.name 起个别名 clazzName,正好落到 Student 对象里那个专门留出来的 clazzName 属性上。用 left join(左连接)——学员班级字段是必填的,正常都能连上,但用左连接的话即使某个 clazz_id 在班级表里不存在,学员本身也不会从列表里消失(课程数据里 clazz_id=2 就是这种情况)。<where> 帮了什么忙:三个条件可以自由组合(可能一个都不传、也可能只传中间那个),动态 SQL 要保证”多一个 and 不行、少一个 and 也不行”。<where> 标签会在有条件时自动补上 where 关键字,并自动去掉紧跟在 where 后头多余的 and(68 篇)。name 用 s.name like concat('%',#{name},'%')——concat 是 MySQL 的字符串拼接函数,拼出 '%张%' 这样两头带通配符的串;degree、clazzId 是 and ... = #{...} 精确匹配。order by s.update_time desc 对应需求里的”根据最后操作时间倒序排序”——刚被编辑/违纪处理过的学员会排在前面,这也是 75 篇反复改 update_time 的意义。<if> 里的 test 写的是方法形参名(name / degree / clazzId),不是列名。GET /students/{id}#需求与接口约定:点行尾的「编辑」,弹窗要先把这名学员的现有信息查出来回显,接口是 GET /students/8(路径参数)。
1// Controller2@GetMapping("/{id}")3public Result getInfo(@PathVariable Integer id){4 Student student = studentService.getInfo(id);5 return Result.success(student);6}1// ServiceImpl:直接返回2@Override3public Student getInfo(Integer id) {4 return studentMapper.getById(id);5}1// StudentMapper:条件简单,注解就够2@Select("select * from student where id = #{id}")3Student getById(Integer id);@PathVariable 把 URL 路径里那一段(/students/ 后面那截)绑到方法形参上——变量名和方法上的 {id} 同名就自动对上(58 篇里查部门详情也是它)。
这里的响应和列表查询有个区别:接口文档 4.4 的详情响应里没有 clazzName(只有 clazzId)——编辑弹窗里”所属班级”是用下拉框选的,前端拿 clazzId 就知道选哪一项,不需要班级名字。所以详情用单表 select * 就够了,不用关联。
PUT /students#需求与接口约定:编辑弹窗改完点保存,前端把学员信息(带 id)以 JSON 放进请求体 PUT 到 /students;只有提交上来的字段才需要更新,最后修改时间由后端补。
1// Controller2@PutMapping3public Result update(@RequestBody Student student){4 studentService.update(student);5 return Result.success();6}1// ServiceImpl2@Override3public void update(Student student) {4 student.setUpdateTime(LocalDateTime.now()); // 最后修改时间由后端补5 studentMapper.update(student);6}1<!-- StudentMapper.xml:<set> + <if> 做到"传了才更新" -->2<update id="update">3 update student4 <set>5 <if test="name != null and name != ''">6 name = #{name},7 </if>8 <if test="no != null and no != ''">9 no = #{no},10 </if>11 <if test="gender != null">12 gender = #{gender},13 </if>14 <if test="phone != null and phone != ''">15 phone = #{phone},16 </if>17 <if test="idCard != null and idCard != ''">18 id_card = #{idCard},19 </if>20 <if test="isCollege != null and isCollege != ''">21 is_college = #{isCollege},22 </if>23 <if test="address != null and address != ''">24 address = #{address},25 </if>26 <if test="graduationDate != null">27 graduation_date = #{graduationDate},28 </if>29 <if test="degree != null">30 degree = #{degree},31 </if>32 <if test="violationCount != null">33 violation_count = #{violationCount},34 </if>35 <if test="violationScore != null">36 violation_score = #{violationScore},37 </if>38 <if test="clazzId != null">39 clazz_id = #{clazzId},40 </if>41 <if test="updateTime != null">42 update_time = #{updateTime}43 </if>44 </set>45 where id = #{id}46</update>这就是 75 篇讲过的动态更新:前端提交了哪些字段就更哪些,没提交的(null)保持库里原值。三个细节:
<set> 标签的两件事:有字段时会自动补 set 关键字,并自动去掉最后多余的那个逗号——所以每个 <if> 里面都能放心地以逗号结尾(包括最后一项)。上面 update_time 那行没写逗号,是因为它固定排在最后;其实写不写都行,<set> 会处理。name、no、phone、idCard、address、isCollege 这些”字符串型”字段写成 test="xxx != null and xxx != ''",避免前端传个 "" 把库里的值覆盖成空串;gender、degree、clazzId、日期这些不是字符串的字段只判 != null 就够了(isCollege 在课程代码里连 != '' 一起判了,它其实是数字,按类型判断就行)。update_time 的 <if> 是”保险丝”:Service 每次修改都会 setUpdateTime,所以这个 <if> 必定命中、<set> 里至少有一项。反过来说,如果某次调用所有字段都是 null,<set> 里就什么都不剩,SQL 会拼成 update student where id = ?——直接语法错误。所以”Service 一定要补时间字段”不只是为了记录,也是在兜这个底。where id = #{id} 里的 id 就是编辑弹窗带回来的 id——没有它这条 SQL 会把全表更新,这是所有 UPDATE 语句的第一大忌。
DELETE /students/{ids}#需求与接口约定:表格加勾选框,勾几行点「批量删除」,前端把选中的 id 拼成 1,2,3 发到 /students/1,2,3;单行的「删除」只传一个 id,走同一个接口(和 74 篇”单条删除也是一种特殊的批量删除”是同一个道理)。注意接口文档 4.2 写的参数格式是路径参数:
1// Controller:接到路径里的一段,绑成一批 id2@DeleteMapping("/{ids}")3public Result delete(@PathVariable List<Integer> ids){4 studentService.delete(ids);5 return Result.success();6}1// ServiceImpl:只有一张表要删,不用事务,直接透传2@Override3public void delete(List<Integer> ids) {4 studentMapper.delete(ids);5}1<!-- StudentMapper.xml:和 74 篇的 foreach 一模一样 -->2<delete id="delete">3 delete from student where id in4 <foreach collection="ids" item="id" separator="," open="(" close=")">5 #{id}6 </foreach>7</delete>把 74 篇的员工删除和这里并排看,差别只有”参数从哪儿来”:
| 删除员工(74 篇) | 删除学员(本篇) | |
|---|---|---|
| 接口 | DELETE /emps?ids=1,2,3 | DELETE /students/1,2,3 |
| 参数格式 | 查询参数(问号后面) | 路径参数(路径里的一段) |
| 控制层注解 | @RequestParam List<Integer> ids | @PathVariable List<Integer> ids |
| XML | <foreach> 拼 in 的括号 | 完全一样 |
@PathVariable 接 List<Integer> 时,Spring 会按逗号把路径里那段 1,2,3 切成三个元素——这是框架自带的规则,不用自己 split。
另一个和员工删除的差别:员工删的时候要删两张表(员工 + 工作经历)、必须加事务;学员这边没有从表(违纪次数、扣分就是 student 里两列),所以一条 SQL 就完事,不需要 @Transactional。别把两件事混在一起背。
PUT /students/violation/{id}/{score}#这是学员管理里最”新”的一个接口,也是页面原型里明确写了两条规则的功能:
1). 每一次违纪处理 , 就需要将违纪次数往上累加一次 。 2). 每一次违纪处理 , 需要将违纪分数累加。
页面上的流程:表格每行的操作列里有一个「违纪」按钮,点它弹出标题为”学员违纪处理”的小弹窗,里面只有一个”违纪扣分”输入框和「确定」「取消」——老师填这次要扣几分,点确定就发请求。
接口约定(接口文档 4.6):PUT /students/violation/{id}/{score},参数格式是路径参数,两个参数分别是 id(学员 ID)和 score(扣除分数),比如 /students/violation/1/5 表示”给 1 号学员记一次违纪、扣 5 分”。
三层实现:这个接口的业务规则全部落在 SQL 里,所以 Service 只做透传。
1// Controller:两个路径参数2@PutMapping("/violation/{id}/{score}")3public Result violationHandle(@PathVariable Integer id , @PathVariable Integer score){4 studentService.violationHandle(id, score);5 return Result.success();6}1// ServiceImpl:没有额外业务,直接调 Mapper2@Override3public void violationHandle(Integer id, Integer score) {4 studentMapper.updateViolation(id, score);5}1// StudentMapper:一条 SQL 完成"次数 +1、分数累加"2@Update("update student set violation_count = violation_count + 1 , violation_score = violation_score + #{score} , update_time = now() where id = #{id}")3void updateViolation(Integer id, Integer score);逐块拆开看这条 SQL:
| 片段 | 作用 |
|---|---|
violation_count = violation_count + 1 | 次数在原来的值上加 1——不是前端传进来的 |
violation_score = violation_score + #{score} | 扣分在原来的值上累加这次传进来的分数 |
update_time = now() | 顺手把最后操作时间刷新(列表按它倒序) |
where id = #{id} | 只改这一个学员 |
三个要点:
{id}、{score} 与方法形参 id、score 同名,@PathVariable 就各就各位(想改名也行,写 @PathVariable("score") Integer s 这种形式即可)。同一个方法上的多个 @PathVariable 会按路径里的顺序对应。violation_count = violation_count + 1 是让数据库在一条语句里原子地基于当前值自增,不会互相覆盖,也少一次查询。课程自带的 18 条数据里就有”累加过”的例子:崔百泉 violation_count=6、violation_score=17,郑成功 2/7——都是这么一次次加出来的。
把工程跑起来,按接口文档发请求,看真实响应和库里的变化。以下都是本机实测结果,连的是 MySQL 的 tlias 库、用户名 root(password 换成你自己 MySQL 的密码)。
① 列表的条件分页查询:
本机实测:
1$ GET http://localhost:8080/students?page=1&pageSize=32{"code":1,"msg":"success","data":{"total":18,"rows":[3 {"id":12,"name":"崔百泉","no":"2022000012","clazzId":8,"violationCount":6,"violationScore":17,...},4 {"id":18,"name":"郑成功","no":"2023001101","clazzId":8,"violationCount":2,"violationScore":7,...},5 {"id":11,"name":"钟万仇","no":"2022000011","clazzId":1,...}]}}total 是 18——库里就 18 名学员。三行依次是崔百泉、郑成功、钟万仇,这个顺序不是按 id 排的,而是按 update_time desc:崔百泉、郑成功都是被改过数据的(就是上面那两个有违纪记录的),所以排在前面。
② 再叠一个条件:按班级筛选:
本机实测:
1$ GET http://localhost:8080/students?clazzId=1&page=1&pageSize=102total: 6 → 钟万仇 / 天山童姥 / 萧峰 / 虚竹 / 萧远山 / 阿朱total 变成 6,正好是 clazz_id=1(JavaEE就业163期)名下的人数——动态 SQL 只把 and s.clazz_id = #{clazzId} 拼了进去,另外两个条件没传就没拼。
③ 违纪处理(本机实测跑的就是下面这一发请求,跑完已把数据还原):
本机实测:
1$ PUT http://localhost:8080/students/violation/1/5 ← 1 号学员(段誉)记一次违纪、扣 5 分2{"code":1,"msg":"success","data":null}3
4# 查库5select violation_count, violation_score from student where id = 1;6 记录前: 0 / 07 记录后: 1 / 5 ← 次数 0→1(SQL 里 +1)、分数 0→5(累加这次扣的 5 分)一次请求、一条 SQL,两个字段都按”累加”的语义变了。按这条 SQL 的语义,接着再调一次 PUT /students/violation/1/3 就会得到 2 / 8——次数再 +1、分数再 +3(练习里会自己动手验证这一步)。
| 问题 | 答案 |
|---|---|
| 学员管理要做几个功能? | 五个:列表查询、删除、添加、修改、违纪处理(对应接口文档第 4 节的六个接口) |
| 本章的规矩是什么? | 严格按接口文档开发:路径、请求方式、参数格式(查询参数 / 路径参数 / JSON)都要对上,然后做前后端联调 |
| 列表查询怎么写? | GET /students;三个条件用 <where> + <if> 动态拼;left join clazz 查出 clazzName;order by s.update_time desc;分页用 PageHelper |
| 详情和修改的区别? | 详情 GET /students/{id} 单表 select *(响应没有 clazzName);修改 PUT /students 用 <set> + <if> 按需更新,Service 补 updateTime |
| 删除学员的参数格式? | 路径参数 DELETE /students/1,2,3,@PathVariable List<Integer> ids;XML 的 <foreach> 和员工删除一模一样(别和 /emps?ids= 混) |
| 违纪处理的接口? | PUT /students/violation/{id}/{score},两个路径参数;id 学员 ID、score 扣除分数 |
| 违纪的 SQL 怎么算? | violation_count = violation_count + 1、violation_score = violation_score + #{score}、update_time = now(),where id = #{id} |
| 为什么在 SQL 里累加? | 一条 SQL 原子完成,避免”先查后改”的丢更新,也少一次查询;次数不需要前端传 |
| 学员表要小心的约束? | no(学号)、phone(手机号)、id_card(身份证号)三个唯一;撞了会被全局异常处理器转成 {"code":0,"msg":"'xxx' 已存在"} |
| 本机实测结果? | 列表 total=18(按 update_time 倒序);clazzId=1 → total=6;PUT /students/violation/1/5 → 段誉 violation_count 0→1、violation_score 0→5 |
资料\02. 接口文档 对上。no(学号)、phone(手机号)、id_card(身份证号)——新增/修改时重复会撞数据库,再由全局异常处理器转成 {"code":0,"msg":"'xxx' 已存在"}。GET /students?name=°ree=&clazzId=&page=&pageSize=;name 模糊(like concat('%',#{name},'%'))、degree 与 clazzId 精确;三个条件都可选;排序按 update_time desc。student 里只有 clazz_id,页面要显示班级名称,所以 select s.*, c.name clazzName from student s left join clazz c on s.clazz_id = c.id,别名 clazzName 正好落到 Student 那个非表字段的属性上。<where> 的作用:有条件时自动补 where,并去掉紧跟其后多余的 and——三个条件任意组合都不会拼错 SQL。GET /students/{id}(@PathVariable,单表查,响应里没有 clazzName);修改 PUT /students(JSON 里带 id)用 <set> + <if> 做到”传了才更新”,<set> 还会自动去掉最后一个多余的逗号。DELETE /students/1,2,3,控制层 @DeleteMapping("/{ids}") + @PathVariable List<Integer> ids;它和员工删除的 DELETE /emps?ids=1,2,3(查询参数)不一样。PUT /students/violation/{id}/{score},两个路径参数(id 学员 ID、score 扣除分数);SQL 里 violation_count = violation_count + 1、violation_score = violation_score + #{score}、update_time = now()。total=18(按 update_time 倒序,崔百泉、郑成功排在前面);clazzId=1 筛出 6 人;PUT /students/violation/1/5 之后段誉的 violation_count 0→1、violation_score 0→5。 2-1 新增学员:把请求体里的 JSON 落成一条记录
需求:页面上点「+ 新增学员」弹窗,填完提交;前端把学员信息(姓名、学号、性别、手机号、身份证号、是否来自院校、联系地址、学历、毕业时间、班级 ID)以 JSON 放进请求体,POST 到 /students。要求三层都写出来:控制层把请求体接成学员对象、业务层补上创建时间与修改时间、数据访问层把记录写进 student 表。写完回答:① 这条 insert 语句为什么不写 violation_count、violation_score 两列?② 如果学号和库里已有学员重复,接口会返回什么?
(练习文件 test_79_学员管理.java 的题目2-1 里给了写作区。)
一级 · 思路:请求体是一整段 JSON → 要有一个能把它整体转成对象的形参;两个时间字段前端不传 → 由业务层用当前时间补上;SQL 只需要写”要落库的那些列”
二级 · 方法:控制层 @PostMapping + @RequestBody Student student;业务层 student.setCreateTime(LocalDateTime.now())、student.setUpdateTime(...);数据访问层注解 @Insert("insert into student(...) values (...)")(69 篇)
三级 · 骨架:
1// Controller2@____3public Result save(@____ Student student){4 studentService.____(student);5 return Result.success();6}7
8// ServiceImpl9public void save(Student student) {10 student.setCreateTime(____);11 student.setUpdateTime(____);12 studentMapper.____(student);13}1// Controller2@PostMapping3public Result save(@RequestBody Student student){4 studentService.save(student);5 return Result.success();6}1// ServiceImpl2@Override3public void save(Student student) {4 student.setCreateTime(LocalDateTime.now());5 student.setUpdateTime(LocalDateTime.now());6 studentMapper.insert(student);7}1// StudentMapper(课程写法:注解)2@Insert("insert into student(name, no, gender, phone,id_card, is_college, address, degree, graduation_date,clazz_id, create_time, update_time) VALUES " +3 "(#{name},#{no},#{gender},#{phone},#{idCard},#{isCollege},#{address},#{degree},#{graduationDate},#{clazzId},#{createTime},#{updateTime})")4void insert(Student student);回答:
① 这两列在表定义里有默认值 0(violation_count tinyint unsigned default 0 not null),新学员没违过纪,插进去就是 0;而且前端表单里也没有”违纪次数/扣分”可填。违纪次数与扣分只由违纪处理接口去改,不经过新增与编辑。
② 学号/手机号/身份证号都带唯一约束,重复时数据库抛 Duplicate entry ... for key 'student.no',Spring 把它翻译成 DuplicateKeyException,被 76 篇的 handleDuplicateKeyException 接住,接口返回 {"code":0,"msg":"'<重复的值>' 已存在","data":null}——不会 500,也不会真的插进去。调试时换个学号/手机号/身份证号即可。
2-2 学员列表的条件分页查询:三个可选条件 + 班级名称
需求:页面顶部三个条件——姓名(模糊)、最高学历(精确下拉)、所属班级(精确下拉),三个都可以留空;列表里”班级”那一列要显示班级名称(不是 ID);结果按最后操作时间倒序、分页显示。要求写全三层,并说明列表 SQL 里为什么要关联班级表。
(练习文件 test_79_学员管理.java 的题目2-2 里给了写作区。)
一级 · 思路:条件可有可无 → 动态 SQL;要显示班级名字 → 关联 clazz 表并起个别名装进实体;分页 → PageHelper 拦下紧跟着的那条查询
二级 · 方法:控制层 @GetMapping 接 name/degree/clazzId + @RequestParam(defaultValue = "1") Integer page/pageSize(68 篇);业务层 PageHelper.startPage(page, pageSize) 后紧跟 studentMapper.list(...),把结果强转 Page<Student> 取 getTotal()(67 篇);数据访问层 XML 里 select s.*, c.name clazzName from student s left join clazz c on s.clazz_id = c.id + <where><if> + order by s.update_time desc
三级 · 骨架:
1<select id="list" resultType="com.itheima.pojo.Student">2 select s.*, ____ clazzName from student s ____ clazz c on s.clazz_id = c.id3 <____>4 <if test="name != null and name != ''">5 s.name like ____('%',#{name},'%')6 </if>7 <if test="degree != null">8 ____ s.degree = #{degree}9 </if>10 <if test="clazzId != null">11 and s.____ = #{clazzId}12 </if>13 </where>14 order by s.update_time ____15</select>1// Controller2@GetMapping3public Result page(String name,4 Integer degree,5 Integer clazzId,6 @RequestParam(defaultValue = "1") Integer page,7 @RequestParam(defaultValue = "10") Integer pageSize){8 PageResult pageResult = studentService.page(name, degree, clazzId, page, pageSize);9 return Result.success(pageResult);10}1// ServiceImpl2@Override3public PageResult page(String name, Integer degree, Integer clazzId, Integer page, Integer pageSize) {4 PageHelper.startPage(page, pageSize);5 List<Student> studentList = studentMapper.list(name, degree, clazzId);6 Page<Student> p = (Page<Student>) studentList;7 return new PageResult(p.getTotal(), p.getResult());8}1<select id="list" resultType="com.itheima.pojo.Student">2 select s.*, c.name clazzName from student s left join clazz c on s.clazz_id = c.id3 <where>4 <if test="name != null and name != ''">5 s.name like concat('%',#{name},'%')6 </if>7 <if test="degree != null">8 and s.degree = #{degree}9 </if>10 <if test="clazzId != null">11 and s.clazz_id = #{clazzId}12 </if>13 </where>14 order by s.update_time desc15</select>为什么要关联班级表:student 表里只有 clazz_id,页面要显示的是班级名称,所以把 clazz 连进来取 c.name,并起别名 clazzName——它正好对应 Student 实体里那个不属于表字段的 clazzName 属性,resultType 一自动映射就装上了。本机实测:不加条件 total=18;加 clazzId=1 后 total=6(钟万仇、天山童姥、萧峰、虚竹、萧远山、阿朱)。
2-3 学员的「编辑」流程:详情回显 + 按需修改
需求:点行尾的「编辑」,弹窗要先把这名学员的信息查出来回显(按 ID 查详情);改完点保存,前端把学员 JSON(带 id)以 PUT 发到 /students,只有提交上来的字段才更新,最后修改时间由后端补。要求写出这两个接口的三层实现,并说明 <set> 这个标签帮了什么忙。
(练习文件 test_79_学员管理.java 的题目2-3 里给了写作区。)
一级 · 思路:详情是”按 id 查一个”→ 路径参数 + 单表查询;修改是”按 id 改若干列”→ 请求体 + <set> 动态更新;updateTime 由 Service 补,这样 <set> 里必定有一项
二级 · 方法:@GetMapping("/{id}") + @PathVariable / @PutMapping + @RequestBody;Mapper 的查询 @Select("select * from student where id = #{id}");XML 里 <update id="update"> 的 <set><if test="列 != null and 列 != ''">列 = #{列},</if></set>,最后 where id = #{id}
三级 · 骨架:
1// Controller2@GetMapping("/{id}")3public Result getInfo(@____ Integer id){4 return Result.success(studentService.____(id));5}6
7@PutMapping8public Result update(@____ Student student){9 studentService.update(student);10 return Result.success();11}12
13// ServiceImpl.update:补 updateTime14student.setUpdateTime(____);1// Controller2@GetMapping("/{id}")3public Result getInfo(@PathVariable Integer id){4 Student student = studentService.getInfo(id);5 return Result.success(student);6}7
8@PutMapping9public Result update(@RequestBody Student student){10 studentService.update(student);11 return Result.success();12}1// ServiceImpl2@Override3public Student getInfo(Integer id) {4 return studentMapper.getById(id);5}6
7@Override8public void update(Student student) {9 student.setUpdateTime(LocalDateTime.now());10 studentMapper.update(student);11}1// StudentMapper:详情条件简单,用注解2@Select("select * from student where id = #{id}")3Student getById(Integer id);1<!-- StudentMapper.xml:按需更新(只列前面几列,其余同理) -->2<update id="update">3 update student4 <set>5 <if test="name != null and name != ''">6 name = #{name},7 </if>8 <if test="gender != null">9 gender = #{gender},10 </if>11 <if test="clazzId != null">12 clazz_id = #{clazzId},13 </if>14 <if test="updateTime != null">15 update_time = #{updateTime}16 </if>17 </set>18 where id = #{id}19</update><set> 帮了两件事:有字段时自动补 set 关键字、自动去掉最后一个多余的逗号(所以每个 <if> 里的 xxx = #{xxx}, 都能放心带逗号)。另外:字符串字段判 != null and != ''(防止把库里的值覆盖成空串),数字/日期字段只判 != null;Service 每次都补 updateTime,所以 <set> 里至少有一项,不会拼出 update student where id = ? 这种语法错误的 SQL。详情响应里没有 clazzName,因为编辑弹窗用 clazzId 选班级,单表 select * 就够。
2-4 批量删除学员(注意路径参数)
需求:表格勾选若干行点「批量删除」,前端把选中的学员 id 拼成 1,2,3 放进路径里发到 /students/1,2,3;单行的「删除」只传一个 id,走同一个接口。要求写全三层,并回答:它和 74 篇的员工删除接口在”参数格式”上差在哪?控制层注解因此有什么不同?
(练习文件 test_79_学员管理.java 的题目2-4 里给了写作区。)
一级 · 思路:参数在 URL 路径里而不是问号后面 → 接参用另一种注解;SQL 是”按一批 id 删除” → in + <foreach>(和员工删除那段完全一样)
二级 · 方法:@DeleteMapping("/{ids}") + @PathVariable List<Integer> ids(对比员工的 @RequestParam List<Integer> ids);XML 里 <delete id="delete">delete from student where id in <foreach collection="ids" item="id" separator="," open="(" close=")">#{id}</foreach></delete>(74 篇)
三级 · 骨架:
1@____("/{ids}")2public Result delete(@____ List<Integer> ids){3 studentService.delete(ids);4 return Result.success();5}1<delete id="delete">2 delete from student where id in3 <foreach collection="____" item="____" separator="," open="(" close=")">4 #{____}5 </foreach>6</delete>1// Controller2@DeleteMapping("/{ids}")3public Result delete(@PathVariable List<Integer> ids){4 studentService.delete(ids);5 return Result.success();6}7
8// ServiceImpl:学员只有一张表要删,不需要事务9@Override10public void delete(List<Integer> ids) {11 studentMapper.delete(ids);12}1<delete id="delete">2 delete from student where id in3 <foreach collection="ids" item="id" separator="," open="(" close=")">4 #{id}5 </foreach>6</delete>回答:员工删除是 DELETE /emps?ids=1,2,3——参数是查询参数(问号后面),控制层用 @RequestParam List<Integer> ids(甚至不写注解的 Integer[] ids 也行);学员删除是 DELETE /students/1,2,3——参数是路径参数(路径里的一段),必须用 @PathVariable List<Integer> ids。Spring 会把路径里逗号分隔的 1,2,3 自动切成三个元素绑进 List。XML 里 <foreach> 的写法两边完全一样。照接口文档写,别把员工那套地址抄过来(会 404)。
3-1 照着课程把”违纪处理”从接口做到数据库,并验证数据是”累加”的 这一题只做一个功能,但要走完”看接口文档 → 写三层 → 发请求 → 查库 → 回头看 SQL → 解释设计”的整条路,每步都留证据。
update),写在 test_79_违纪处理.java 里;id 和当前的 violation_count / violation_score(比如 select id, name, violation_count, violation_score from student where violation_count = 0;);PUT http://localhost:8080/students/violation/<id>/5,把响应的 JSON 抄下来;violation_count 与 violation_score 的新值抄下来——数一数次数涨了几、分数涨了几;PUT /students/violation/<id>/3(这次扣 3 分),再查库,把两个字段的新值抄下来;StudentMapper 里把这条 SQL 原文抄出来,圈出”哪一部分是次数 +1""哪一部分是分数累加""哪一部分保证只改这一个学员”;(练习文件 test_79_违纪处理.java 的题目3-1 里按这 7 步给了写作区。)
回答:① 如果把违纪处理改成”先 getById 查出来、在 Java 里把次数 +1、分数加上去,再调 update 写回”,会有什么风险?② 这个接口为什么把”扣多少分”设计成一个路径参数、让前端传,而”违纪次数”却要后端自己加?
涉及知识点
| 知识点 | 在这里的应用 |
|---|---|
| 接口文档 4.6 违纪处理 | 第 1、3 步——PUT /students/violation/{id}/{score},两个路径参数 |
@PathVariable | 第 1、3 步——两个同名形参自动接住路径里的 id 与 score |
| 一条 SQL 完成累加 | 第 4、5、6 步——violation_count = violation_count + 1、violation_score = violation_score + #{score} |
where id = #{id} | 第 6、7 步——算错条件就会改到所有人 |
| 读-改-写的并发问题 | 第 7 步——先查后改会丢更新 |
| 本机实测 | 第 3~5 步——段誉 0/0 → 1/5 |
一级 · 思路:路径里两段 {id}、{score} 各需要一个 @PathVariable 形参;业务规则写在 SQL 里——“次数在原值上加 1""分数在原值上加这次扣的分”
二级 · 方法:@PutMapping("/violation/{id}/{score}") + @PathVariable Integer id, @PathVariable Integer score;Mapper 用 @Update,SQL 是 update student set violation_count = violation_count + 1, violation_score = violation_score + #{score}, update_time = now() where id = #{id}
三级 · 骨架:
1@PutMapping("/violation/{____}/{____}")2public Result violationHandle(@PathVariable Integer id , @PathVariable Integer score){3 studentService.____(id, score);4 return Result.success();5}1@Update("update student set violation_count = violation_count + ____ , violation_score = violation_score + ____ , update_time = now() where id = ____")2void updateViolation(Integer id, Integer score);1. 三层代码(课程 StudentController.violationHandle / StudentServiceImpl.violationHandle / StudentMapper.updateViolation):
1@PutMapping("/violation/{id}/{score}")2public Result violationHandle(@PathVariable Integer id , @PathVariable Integer score){3 studentService.violationHandle(id, score);4 return Result.success();5}1@Override2public void violationHandle(Integer id, Integer score) {3 studentMapper.updateViolation(id, score);4}1@Update("update student set violation_count = violation_count + 1 , violation_score = violation_score + #{score} , update_time = now() where id = #{id}")2void updateViolation(Integer id, Integer score);2. 找一个没被处理过的学员:本机实测挑的是 id=1 段誉(violation_count=0、violation_score=0)。
3. 请求与响应(本机实测):
1$ PUT http://localhost:8080/students/violation/1/52{"code":1,"msg":"success","data":null}4. 第一次查库:violation_count 0 → 1(涨了 1),violation_score 0 → 5(涨了这次扣的 5 分)。
5. 再扣 3 分:本机实测只跑了第 3 步那一发(跑完已把数据还原成 0/0);你自己按第 5 步再发一次 PUT /students/violation/1/3 之后查库,violation_count 会是 2、violation_score 会是 8——次数再 +1、分数再 +3,是在上一次的结果上继续加,不是重置。
6. SQL 三个部位:
violation_count = violation_count + 1;violation_score = violation_score + #{score}(#{score} 就是路径里传进来的那个分数);where id = #{id}(少了它会把全表所有人都记一次违纪)。
另外 update_time = now() 顺手刷新最后操作时间,列表按 update_time desc 排序,刚被处理过的学员会冒到最前面。
7. 两个回答:
① 会丢更新。“查 → 在 Java 里算 → 写回”是三步,中间有时间间隙:两个老师同时给同一个学员记违纪,可能都先读到 violation_count=3,各自在内存里算成 4,再分别写回 4——数据库里最终只涨了 1 次,另一次被覆盖了(典型的读-改-写并发问题)。写成 violation_count = violation_count + 1 是把”读当前值、加 1、写回”合成一条 SQL 原子执行,两个请求先后到达都会正确累加,而且少了一次查询。
② “扣多少分”是这次操作的输入,只有前端(老师点的那个弹窗)知道,所以做成参数传进来;“已经违纪几次”是库里的状态,前端手里的值可能已经过期,让它传反而有覆盖成旧值的风险,所以由后端在 SQL 里”在现有值上加 1”。一句话:输入参数传进来,状态字段库内自增。如果你喜欢,那么欢迎来到我的世界!
